Docker Compose - Online

Introduction

This document aims to explain how to install Exastro Platform or Exastro IT Automation on Docker or Podman.

Features

This is the easiest and simplest way of installing Exastro IT Automation

For higher availability and service level, we recommend Kubernetes version

Pre-requisites

• Deploy environment

  The hardware requirements for the Container environment are as follows.

  Table 27 Hardware requirements(Minimum)

  Resource type	Required resource
  CPU	2 Cores (3.0 GHz, x86_64)
  Memory	4GB
  Storage (Container image size)	35GB

  Table 28 Hardware requirements(Recommended)

  Resource type	Required resource
  CPU	4 Cores (3.0 GHz, x86_64)
  Memory	16GB
  Storage (Container image size)	120GB

※ The system must have disk space as partitions.

▼RHEL

・Container image

/home/Username/.local 25GB

・Exastro data

/home/Username/exastro-docker-compose 10GB(rough estimate. May change depending on usecases).

▼Other than RHEL

・Container image

/var/lib/ 25GB

・Exastro data

/home/Username/exastro-docker-compose 10GB(rough estimate. May change depending on usecases).

Warning

The required resources for the minimum configuration are for when both Gitlab Container and OASE container are not deployed. Additional resources will be required if you are planning to deploy them.

Users will have to prepare an additional storage area if they wish to persist databases or files.

The storage space is only an estimate and varies based on the user’s needs. Make sure to take that into account when securing storage space.

• Communication Protocols

  Table 29 Communication Protocols

  Use	Description	Source	Destination	Default
  For Exastro service	For connecting to Exastro service	Client	Exastro system	30080/tcp
  Exastro system (management)	For Exastro system management function	Client	Exastro system	30081/tcp
  GitLab service(options)	For connecting to GitLab when linked with AAP	Ansible Automation Platform	Exastro system	40080/tcp
  For GitLab service (option)	For monitoring GitLab service	Exastro system	Exastro system	40080/tcp
  File acquisition	GitHub, Container images, Packages, etc.	Exastro system	Internet	443/tcp

• Confirmed compatible Operation systems

  The following describes confirmed compatible operation systems as well as their versions.

  Table 30 Operating systems

  Type	Version
  Red Hat Enterprise Linux	Version 8
  AlmaLinux	Version 8
  Ubuntu	Version 22.04

• Confirmed compatible Operation systems and container platforms

  The following describes confirmed compatible operation systems as well as their versions.

  Table 31 Tested environments

  OS version	podman version	Docker Compose version	Docker version
  Red Hat Enterprise Linux release 9.4 (Plow)	podman version 4.9.4-rhel	Docker Compose version v2.20.3	ー
  Red Hat Enterprise Linux release 8.9 (Ootpa)	podman version 4.9.4-rhel	Docker Compose version v2.20.3	ー
  AlmaLinux release 8.9 (Midnight Oncilla)	ー	ー	Docker version 26.1.3, build b72abbb

Tip

Some users have been meeting errors where the name cannot be resolved correctly in rootless mode in RHEL 8.2 or podman 4.x. Make sure to use RHEL 8.3 or later.

https://github.com/containers/podman/issues/10672

https://github.com/containers/podman/issues/12565

• Applications

  The user must be able to run curl and sudo commands.

Warning

The Exastro process must be able to be run with normal user permissions (it is not possible to install with root user).

Any normal users must be sudoer and have complete permissions.

Preparation

The user must prepare an URL for releasing the service.

Table 32 Example 1) Releasing service with IP Address

Service	URL
Exastro service	http://172.16.0.1:30080
Exastro management service	http://172.16.0.1:30081
GitLab service	http://172.16.0.1:40080

Table 33 Example 2) Releasing service with Domain

Service	URL
Exastro service	http://ita.example.com:30080
Exastro management service	http://ita.example.com:30081
GitLab service	http://ita.example.com:40080

Table 34 Example 3) Releasing service through LoadBalancer

Service	URL
Exastro service	https://ita.example.com
Exastro management service	https://ita-mng.example.com
GitLab service	https://gitlab.example.com

Tip

If the user is using HTTPS, they must use either LoadBalancer or Reverse proxy.

If the user plans to use LoadBalancer or Reverse proxy, they will have to prepare that themselves.

Installation (Automatic)

Note

The installer selects either Docker or Podman depending on the user OS.

Note

If the installer fails, run Uninstall’s Deleting Container and Data or Leaving the Container image and try installing again.

The easiest way of installing Exastro ITA is to use the the Installation script.

This allows users to start the installation process with 1 command.

The following is an example where the user is “test_user” and the home directory is “/home/test_user”.

Listing 107 Install command

sh <(curl -sf https://ita.exastro.org/setup) install

After the install command is run, the system will check that the system requirements are met before starting the Container construction process.

When all the required packages are installed, the user will be able to customize the installation with the following values:

Listing 108 Confirm OASE container deployment

Deploy OASE containers? (y/n) [default: y]:

Listing 109 Confirm GitLab container deployment

Deploy GitLab container? (y/n) [default: n]:

Listing 110 Confirm automatic password generation?

# Asks to automatically generate Maria DB and System admin password.
Generate all password and token automatically? (y/n) [default: y]:

https encrypted connectionhttp connection

Listing 111 Exastro service URL

#Input 30800 for the port number if the OS is Red Hat Enterprise Linux. For everything else, input 80.
Input the Exastro service URL: https://ita.example.com:30080

Listing 112 Exastro management service URL

#Input 30801 for the port number if the OS is Red Hat Enterprise Linux. For everything else, input 81.
Input the Exastro management URL: https://ita.example.com:30081

Listing 113 Self-signed SSL/TSL certificate generation (If Exastro service URL/Exastro management service URL is set to https)

Generate self-signed SSL certificate? (y/n) [default: y]:

Listing 114 Server certificate/Secret key file path (If Self-signed SSL/TSL certificate generation is set to “n”)

#Specify the server certificate file path for the certificate file path and the secret key file's file path for the private-key file path.
Input path to your SSL certificate file.
certificate file path:
private-key file path:

Listing 116 Gitlab container URL(Required if deploying Gitlab container).

Input the external URL of GitLab container [default: (nothing)]:

Tip

Make sure to include the port number in the URL.

Specify 40080 for the port number.

Listing 117 Exastro service URL

Service URL? [default: http://127.0.0.1:30080]: http://ita.example.com:30080

Listing 118 Exastro management service URL

Management URL? [default: http://127.0.0.1:30081]: http://ita.example.com:30081

Listing 119 Confirm generated settings file

System parametes are bellow.

System administrator password:    ********
Database password:                 ********
OASE deployment                   true
MongoDB password                  ********
Service URL:                      http://ita.example.com:30080
Manegement URL:                   http://ita.example.com:30081
Docker GID:                       1000
Docker Socket path:               /run/user/1000/podman/podman.sock
GitLab deployment:                false

Generate .env file with these settings? (y/n) [default: n]:

Inputting either y or yes will download all Docker Compose files needed to run Exastro from GitHub and change the firewall settings.

Listing 120 Check Exastro container deployment

Deploy Exastro containers now? (y/n) [default: n]:

Input either n or no to edit settings on a more granular level and skip skip the following process.

Input either y or yes to run the Exastro system container group.

The Exastro system deployment process may take several minutes (Depends on the network situation and server specs).

Listing 121 Running Exastro container deployment

Please wait for a little while. It will take 10 minutes or later..........

When the Exastro system deployment is finnished, the service connection information will be output.

Listing 122 Service connection information outpu

System manager page:
  URL:                http://ita.example.com:30081/
  Login user:         admin
  Initial password:   ******************

Organization page:
  URL:                http://ita.example.com:30080/{{ Organization ID }}/platform


GitLab service is has completely started!

Run creation organization command:
   bash /home/test_user/exastro-docker-compose/create-organization.sh


! ! ! ! ! ! ! ! ! ! ! ! ! ! !
! ! !   C A U T I O N   ! ! !
! ! ! ! ! ! ! ! ! ! ! ! ! ! !

Be sure to reboot the you host operating system to ensure proper system operation.

Reboot now? (y/n) [default: y]: y

If neccesary, save the output information and press y or yes to restart the system.

Note

The generated parameters are saved under ~/exastro-docker-compose/.env.

Create Organization

After rebooting and logging in to the system, create an organization.

Tip

When linked to GitLab, the GitLab must be running in order to create Organizations.

Create Workspace

After creating an organization, log in to it and create a workspace.

Let’s give it a Try!!

We recommend users go through Quick Start in order to learn how to use the software.

The Quickstart guide guides the user through scenarios where they learn how to use Exastro IT Automation, how the parameter sheets works, etc.

Update

This section describes how to update the Exastro system.

Update preparation

Warning

We recommend that the back up their data before updating.

The backup target is ~/exastro-docker-compose/.volumes.

Update repository

Update the exastro-docker-compose repository.

Listing 123 Command

# Check exastro-docker-compose repository
cd ~/exastro-docker-compose
git pull

Check default setting values and update data

Check the updated default values.

Compare the exastro.yaml file pre and post update.

Listing 124 Command

cd ~/exastro-docker-compose

# For AlmaLinux or Ubuntu OS
diff .env .env.docker.sample
# For Red Hat Enterprise Linux OS
diff .env .env.podman.sample

Update setting values

After comparing the default setting values, add any desired items and setting values before updating.

If no setting value update is needed, skip this step.

Update Execute

Start update

Start the update.

Listing 125 Command

sh <(curl -sf https://ita.exastro.org/setup) install

Uninstall

This section explains how to uninstall Exastro.

Uninstall preparation

Warning

We recommend that back up the data before uninstalling.

The backup target is ~/exastro-docker-compose/.volumes.

Uninstall Execute

Start uninstall

Deleting Container and Data

Deletes the Container image as well.

Listing 126 Command

sh <(curl -sf https://ita.exastro.org/setup) remove -c

Leaving the Container image

Delete Container

Listing 127 Command

sh <(curl -sf https://ita.exastro.org/setup) remove

Delete Volume

Listing 128 Command

docker volume rm $(docker volume ls -qf dangling=true)

# Confirm that the Volume has been deleted
docker volume ls

Delete .volumes

Listing 129 Command

cd ~/exastro-docker-compose

sudo rm -rf .volumes

Recreate .volumes

Note

Make sure to run the command below if re-installing.

Listing 130 Command

cd ~/exastro-docker-compose

git checkout .volumes
